Mounted straight

Tilted sound dispersion. Mounted straight.

5° tilted sound beam

The Fohhn LXP product line comes with the "mounted straight " feature. The sound dispersion of the line source systems (LXP-60, LXP-100 & LXP-150) is tilted down by a fixed 5°. This applies not only to the high frequencies - also the sound from the 4" chassis is tilted by a fixed 5° through passive Fohhn Beam Steering Technology. This eliminates the need for mechanical tilt in many applications and makes mounting even easier. Please note that with the LXP-220, the angle is reduced to 2° for extra-long throw.

Products with tilted sound dispersion

Image of our product LXP-60

LXP-60

passive line source speaker for music and speech - with 5° acoustic pre-tilt , 4 × 4" / 1", 240 W, 117 dB SPLmax, 133 × 641 × 128 mm
Image of our product LXP-100

LXP-100

passive line source speaker for music and speech - with 5° acoustic pre-tilt, 8 × 4" / 1", 480 W, 123 dB SPLmax, 133 × 991 × 128 mm
Image of our product LXP-150

LXP-150

passive line source speaker for music and speech - with 5° acoustic pre-tilt, 12 × 4" / 1", 720 W, 127 dB SPLmax, 133 × 1465 × 128 mm
Image of our product LXP-220

LXP-220

passive line source speaker for music and speech - with 2° acoustic pre-tilt, 18 × 4" / 2 × 1", 900 W, 129 dB SPLmax, 133 × 2201 × 128 mm

Use Case 1

Community hall

Even the shortest LXP line source system can be sufficient to provide high-quality sound in larger rooms. Thanks to the 5° tilt, the speaker can usually be mounted straight against the wall and blends in discreetly next to a projection screen.

Benefits
  • Directed sound dispersion
  • Minimization of interfering reflections
  • Best speech intelligibility
  • No mechanical tilt necessary
  • Economical solution
Components

Use Case 2

Mobile application

LXP also performs well in mobile applications. With improved low-end and even more dynamics than the predecessor, live music also becomes a pleasure to listen to. Of course, a Fohhn subwoofer is recommended for bass supplementation.

Benefits
  • Optimized for clear speech & music
  • Weatherproof according to IP52; IP54 with accessories
  • In black and white in stock
  • Optionally in numerous special colors
Components

Use Case 3

Church

LXP systems are a first-class solution for acoustically challenging rooms. The directional dispersion combined with the 5° tilt ensures that the sound is directed towards the listeners and minimizes reflections from the ceiling and the back wall of the building.

Benefits
  • Clear speech in every row
  • Discreet mouning without tilt possible
  • Also suitable for church bands
  • Available in stone and wood optics
Components
